DIB98JQ50B

Product is no longer available

More information and services related to this product

DIB98JQ50B

Product is no longer available

More information and services related to this product

Technical Overview

Sound power at max. speed (2010/30/EC)
54 dB
Max. air extraction
445 m³/h
Boost position air extraction
867 m³/h
Colour of the body
Stainless steel
Material of the body
Stainless steel
Built-in / Free-standing
Built-in
Width
90 cm

Highlights

Awards

Visual badge of the award

Specifications

Width
90 cm
Colour of the body
Stainless steel
Installation typology
Island
Ventilation mode
Convertible
Total power of the motors
160 W
Type of control setting and signalling devices
touch control
Number of speed settings
3-stage + 2 intensive
Max. air extraction
445 m³/h
Boost position air extraction
867 m³/h
Sound power at max. speed (2010/30/EC)
54 dB
Sound power boost (2010/30/EC)
69 dB
Max. air recirculation
353 m³/h
Boost position output recirculating
457 m³/h
Sound power at max. speed (recirculation)
67 dB
Sound power boost (recirculation)
71 dB
Grease filter material
Washable stainless steel
Total annual energy consumption
31.9 kWh/annum
Height of the appliance
46 mm
Width of the appliance
898 mm
Depth of the product
600 mm
Height of the chimney
698-878/698-998 mm
Minimum distance above an electric hob
550 mm
Minimum distance above a gas hob
650 mm
Diameter of air outlet
120 / 150 mm
No-return airflow flap
No
Length electrical supply cord
130 cm
Net weight
28.7 kg
1 / 0
Photo Nr. 1 of the product
Photo Nr. 2 of the product
Photo Nr. 3 of the product
Automatic air sensor
Yes
Extremely quiet and powerful brushless BLDC motor
Yes
Extremely silent appliances
Yes
Clean filter reminders
Yes
Boost position
Yes
Delay shut off modes
Yes
Remote control
No
Type of lamps used
LED
Color temperature
Neutral (3.500 K)
Ambient light
No
Connected applianceFootnote 1: Some of the features displayed can be accessed only if the device is connected to a Home Connect Account and a SingleKey ID account via the Internet. Home Connect is a service of Home Connect GmbH. For more information on Home Connect, visit www.home-connect.com.
No
Cooktop-based hood control
No
